PVC Pipe Extrusion Production Making Machine Line For Corrugation Drainage

Brand Name : LB

Model Number : LB-110

Certification : CE ISO9001

Place of Origin : ZHANGJIAGANG, JIANGSU

MOQ : 1 SET

Price : USD EUR

Payment Terms : L/C, T/T

Supply Ability : 15 SETS PER MONTH

Delivery Time : 30 WORKING DAYS

Packaging Details : NORMAL PACKAGE

PIPE DIAMETER : 75-250

EXTRUDER'S POWER : 55KW

COLOUR : CUSTOMIZED

PIPE UMBERS : SINGLE PIPE

RAW MATERIAL : PVC POWDER & ADDITIVES

APPLICATION : WATER SUPPLY PIPE

Voltage : 380V 50Hz or customized

Automatic grade : Full-automatically

Screw design : Twin screw and barrel

After-sales service provided : Engineers available to service machinery overseas,Field installation,commissioning and training,Online support,Video technical support

Warranty : 18 months

Inverter : ABB

Color : Customizable

Raw material : PVC Powder

Motor : SIEMENS Brand

Contactor : SIEMENS OR SCHNIDER

Screw and barrel : Conical twin screw extruder

Screw diameter : 65/132

Pipe Application : Water Supply

Packages : Film and boxes

Payment : T/T, L/C, Western Union

Delivery time : 60 days

Contact Now

PVC Pipe Extrusion Production Making Machine Line Corrugation Drainage

Short desciption

PVC plastic Pipe Production Line is mainly used in the production of agricultural drainage, water supply and drainage, and cable laying,etc. purposes. The unit consists of conical double/ parallel double extruder, mold, vacuum forming tank, multi-claw haul-off machine, planetary(chipless) cutting machine, stacker and so on. And the line can be equipped with Comptroller thickening instrument or computer inkjet printer, etc. to achieve the production and manufacture of high-grade tubing.

Tech Features & Advantages

High Output Capacity:Produces corrugated PVC pipes in various diameters (typically 100mm–1000mm) with consistent quality.
Energy-Efficient Extrusion:Utilizes a twin-screw extruder for stable melting and uniform material distribution.
Advanced Corrugation System:Hydraulic or vacuum molding ensures precise wave patterns for optimal drainage performance.
Automated Cutting & Stacking:Computer-controlled cutting for accurate lengths, with optional automatic stacking.
Durable & Low Maintenance:Robust construction with corrosion-resistant components for long-term operation.
Customizable Options:Adjustable for different pipe sizes, wall thicknesses, and corrugation designs. ​

Producting process

PVC powder + additive — mixing—material feeder—twin screw extruder—mould and calibrator—vacuum and cooling tank—spraying cooling machine—haul-off machine—cutting machine—discharge rack or pipe belling machine.

Specifications:

MODEL PIPE DIAMETER (MM) EXTRUDER MODEL MOTOR POWER (KW)
LB-32F 16-32 (FOUR PIPE) SJSZ65/132 37 AC
LB-32E 16-32 (DOUBLE PIPE) SJSZ51/105 22 AC
LB-32W 16-32 (DOUBLE PIPE) SJSZ65/132 37 AC
LB-40E 16-40 (DOUBLE PIPE) SJSZ51/105 22 AC
LB-40W 16-40 (DOUBLE PIPE) SJSZ65/132 37 AC
LB-50E 16-50 (DOUBLE PIPE) SJSZ51/105 22 AC
LB-50W 16-50 (DOUBLE PIPE) SJSZ65/132 37 AC
LB-63W 16-63 (DOUBLE PIPE) SJSZ65/132 37 AC

Product detail

1. Raw Material Preparation
PVC Resin Mixing:PVC powder is blended with stabilizers, plasticizers, and other additives in a mixer.
Drying (if needed): The mixture is dried to remove moisture before extrusion.

2. Extrusion Process
Feeding:The PVC compound is fed into the twin-screw extruder.
Melting & Compression: The material is heated and compressed into a molten state.
Pipe Formation:The molten PVC is pushed through adie head to form a smooth pipe.

3. Corrugation Molding
Vacuum or Hydraulic Molding: The hot pipe passes through a corrugation mold, where vacuum or hydraulic pressure shapes it into a corrugated structure for enhanced strength.
Cooling:Water-cooling systems solidify the pipe into its final shape.

Technical Features:
1. THe plastic pulverizer can easy to grind all kinds of Hard & Soft PVC into powder.
2. The dust collector is added to effectively reduce dust pollution.
3. The discharging of the main fan reduces the labor intensity of operating workers.
4. The door cover of the host can be opened for the convenience of maintenance and replacement of cutters.
5. The mill uses the water and wind double cooling system, Prevent bearing, and other parts from overheating.
6. The powder mesh is adjustable(15-100mesh).
7. Easy installation and maintenance, just open the door to clean up.
Delivery information:
1. Delivery: 30 days after ur order
2. Warrenty: 12 months
3. Payment: T/T 30% in advance, T/T 70% before delivery.
4. Packing: Standard export wooden case
Our Service
1. One year guarantee for whole machine.
2. 24 hours technical support.
3. Our engineers can provide installation & commission service overseas.
4. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price.
5. We also can provide training service which help operators handle the machine well.
